BIA-FC300T CAST IRON CENTRIFUGAL PUMP CLEAN WATER 450L/MIN 38M 3000W 415V

A$1,629.00

Brand: Bianco
Model: BIA-FC300T
Availability: In Stock

Qty

The pump is a horizontal single stage cast iron centrifugal pump supplied ready to install.

Used especially for water transfer.

The pump is characterised by:

• Corrosion resistant cast iron pump body and bracket cover with cataphoresis1 treatment, and 304 stainless steel impeller and shaft.

• Mechanical shaft seal.

• 415V three phase TEFC .

• Motor support foot.

Applications:

Suitable for industrial wash down, water transfer and tank filling.

Suitable for fire fighting, HVAC, circulation and pressure boosting.

Cataphoresis is an electrochemical coating process for metallic surfaces widely used in the industry due to its penetration and long life, either as a priming coat or finished paint for corrosion resistance.

Package Information:

• 41.8 kg

• L 507mm x W 304mm x H 372mm

Centrifugal Pump
Cataphoresis coating, stainless steel impeller.
3.0kW, 4.0hp, 415V, max hd 38m, max flow 450L/m.
Ports 2” BSPF In, 2” BSPF Out.

Warranty

2 Year BIANCO Pumpz Warranty

Features and technical specification of the product. Please contact us for further information and specifics.
Amps	8.2 Amps
Bar	3.8 Bar
Product Type	Single Stage Cast Iron Centrifugal Pump
Power	4.0 Hp, 3.0 kW
Max Head	38 m
Max Flow	450 L/min
Voltage	415 V
Warranty	24 Months

BIA-FC300T CAST IRON CENTRIFUGAL PUMP CLEAN WATER 450L/MIN 38M 3000W 415V

Documents:

Product Information and Data Sheets

Download Product Information & Data Sheetsv1.0

Product Brochures

Download Brochuresv1.0

Spare Parts Information and Exploded Diagrams

Download Spare Parts Information & Exploded Diagramsv1.0

Operation and Installation Manuals

Download Operation & Installation Manualsv1.0
